标准规范
Model |
A (mm) |
B (mm) |
C (mm) |
D (mm) |
H (mm) |
In/Out |
Flowrate (m3/hr) |
No. Bags |
BFM-450-2F | 150 | 1100 | 1430 | Φ450 | 590 | 3" | 60 | 2 |
BFM-500-3F | 150 | 1190 | 1540 | Φ500 | 640 | 4" | 90 | 3 |
BFM-550-4F | 150 | 1200 | 1560 | Φ550 | 690 | 4" | 120 | 4 |
BFM-600-4F | 150 | 1250 | 1630 | Φ600 | 760 | 5" | 120 | 4 |
BFM-600-5F | 150 | 1250 | 1630 | Φ600 | 760 | 5" | 150 | 5 |
BFM-650-5F | 180 | 1350 | 1740 | Φ650 | 830 | 6" | 150 | 5 |
BFM-700-6F | 200 | 1380 | 1780 | Φ700 | 860 | 6" | 180 | 6 |
BFM-800-8F | 200 | 1460 | 1920 | Φ800 | 980 | 8" | 240 | 8 |
BFM-850-9F | 200 | 1470 | 1950 | Φ850 | 1030 | 8" | 270 | 9 |
BFM-900-10F | 250 | 1550 | 2050 | Φ900 | 1100 | 8" | 300 | 10 |
BFM-1000-12F | 250 | 1570 | 2100 | Φ1000 | 1200 | 8" | 360 | 12 |
BFM-1100-16F | 250 | 1600 | 2150 | Φ1100 | 1400 | 8" | 480 | 16 |
BFM-1200-18F | 300 | 1780 | 2350 | Φ1200 | 1500 | 10" | 540 | 18 |
